Hack In Paris Challenge 4¶
The challenge began on Friday April, 8th, with a tweet:
Make your dream come true, #HIPChall n°4 is up!
#YubiKeyNeo & 2 #goldenticket for #HIP16
Hack, Love, Share, & enjoy!
https://hackinparis.com/challenge-4.html …
The web page given by the tweet contains the following message:
Hi !
I have found a strange PDF file that seems to contain some interesting data but I didn't know how to extract and read them.
Can you help me?
https://hackinparis.com/data/chall2016/step-4/dump.pdf
md5 fac78b48bf9603fd52b2f2156d587f1d
sha1 0a7cc0598b5432f7c387a6b5cf8d73409209bcfd
Please send your conclusions (and the validation flag) to merenwen@hackinparis.com
A PDF file which is also an ELF file and a ZIP file¶
The downloaded file is a polyglot file: it is both an ELF file, a PDF file and a ZIP file:
$ binwalk dump.pdf
DECIMAL HEXADECIMAL DESCRIPTION
--------------------------------------------------------------------------------
0 0x0 ELF, 32-bit LSB executable, Intel 80386, version 1 (SYSV)
716 0x2CC PDF document, version: "1.4"
[...]
842635 0xCDB8B Zip archive data, encrypted at least v1.0 to extract, compressed size: 57, uncompressed size: 45, name: README.txt
842776 0xCDC18 Zip archive data, encrypted at least v2.0 to extract, compressed size: 14476, uncompressed size: 17920, name: pass.png
857334 0xD14F6 Zip archive data, encrypted at least v1.0 to extract, compressed size: 15269, uncompressed size: 15257, name: a.zip
872915 0xD51D3 End of Zip archive
The PDF file contains the hexdump of this image:

The ZIP file requires a password to be extracted and the ELF file seems to test a password given by its standard input.
Here is an extract of the output of objdump -Mintel -d dump.pdf
with some comments:
80480f1: bb 01 00 00 00 mov ebx,0x1
80480f6: b8 03 00 00 00 mov eax,0x3
80480fb: 89 e1 mov ecx,esp
80480fd: ba 64 00 00 00 mov edx,0x64
8048102: cd 80 int 0x80 # syscall(read, fd=1, buf=esp, count=100)
8048104: 83 f8 0c cmp eax,0xc
8048107: 0f 85 8a 00 00 00 jne 0x8048197 # Read 12 bytes
804810d: 89 e2 mov edx,esp
804810f: 8b 02 mov eax,DWORD PTR [edx]
8048111: 3d 46 6b 6f 70 cmp eax,0x706f6b46
8048116: 75 7f jne 0x8048197 # The first ones have to be "Fkop"
8048118: 83 c2 04 add edx,0x4
804811b: 8b 1a mov ebx,DWORD PTR [edx]
804811d: 31 d8 xor eax,ebx
804811f: 3d 72 4a 00 00 cmp eax,0x4a72
8048124: 75 71 jne 0x8048197 # The 4 next ones have to be "4!op"
8048126: 83 c2 04 add edx,0x4
8048129: 8b 1a mov ebx,DWORD PTR [edx]
804812b: 31 d8 xor eax,ebx
804812d: 3d 3e 27 39 0a cmp eax,0xa39273e
8048132: 75 63 jne 0x8048197 # The 4 next ones have to be "Lm9\n"
The password seems to be Fkop4!opLm9
:
$ ./dump.pdf
What's the pass?
Fkop4!opLm9
Rename the file in chall.zip and use this password.
How to crack an encrypted message in a corrupted image¶
The ZIP archive can then be decrypted. It contains three files:
README.txt
: contains “The archive password is in the PNG picture.”pass.png
: an invalid PNG image (it can’t be opened with a standard image viewer)a.zip
: an encrypted ZIP archive
The PNG image is invalid because the CRC field of every chunk is zero. The CRC checksums can be fixed using a program such as http://schaik.com/png/pngcsum.html , which allows viewing the image. It contains the following text:
CGEJDH AGBIBJ AFEGBG BJAFEH EJDHAJ AIEJBI EFBJAH
EHDHAG AJEGCG CGDIAJ AJAIEG BGBGEI BFDICG BIEIDF
AFDIBF AFEFEH AJCIDI AJAJBJ AGDIEH AFDJEH BGBGEF
DIBGDF EIEJEG AFEJCG EJBIBI DICGAF BGEIEJ DFDIDH
AFEFDI CFEHDF AIEHBG DIDGEI AGEHAH EHDHAG EIEJEG
AFEFDI BIEHAG EFAFDF BJAJAJ DJEJBI BFBFEJ DHAFAI
EJBIAG DIAFEI EJEGAJ EFEJEG BGBFDJ BIEHAF DIEHAF
EHDHBG EJDJDI BICGBJ AJDIBG DIAFAF DIBIAJ AFEFDI
DFBJAJ AJDJEJ BIBFEH AJAFDG AFBJDH AJDIEI AJBJDI
EHEJCI AJDFEF DIAJBG
The first column only contains letters A, C, D, E, the second one only F, G, H, I, J, the third one B, D, E...
It seems more logical to combine the letters by pairs: the first letter being in {A, B, C, D, E} and the second one in {F, G, H, I, J}.
This looks like an encryption with the Polybius square algorithm, where each letter pair is associated to a character.
As it is a substitution cipher, it may be possible to guess some words... for example “password” seems to be DF BJ AJ AJ DJ EJ BI BF
(which appears 2 times).
This leads to the following substitution array:
A? B? C? D? E?
?F t d z p h
?G g l c b u
?H v ? ? n i
?I f r m e y
?J s a ? w o
The message is therefore: “Congratulations for having successfully decrypted this message. It will help you to correctly open the zip file by giving you the right password. Don’t forget you should write it in lowercase letters. The password is tbtanseysaeiomsphesl”.
This gives the password which is needed to decrypt a file named chall.bin
in a.zip
archive.
This file is an ELF program:
$ file chall.bin
chall.bin: ELF 64-bit LSB executable, x86-64, version 1 (SYSV), dynamically linked,
interpreter /lib64/ld-linux-x86-64.so.2, for GNU/Linux 2.6.24,
BuildID[sha1]=88f9eadd2bf8128ca309a8dc627e18c82c2755a3, stripped
chall.bin
, a brainfuck interpreter in bytecode¶
chall.bin
is an interpreter for a custom bytecode language.
The state of the interpreted program (the “virtual machine”) is allocated on the stack of function main()
(at .text:400B28
) and initialized by the function at address .text:400D2A
.
This state has the following structure:
- offsets 0x00..0x27:
int32 regs[10]
, ten 32-bit integer registers - offsets 0x28..0x2b:
int32 sp
, the stack pointer, offset of the “top” of the stack (which is reverted like x86 CPU) - offsets 0x2c..0x2f:
int32 ip
, the instruction pointer, offset of the current instruction in the program - offsets 0x30..0x33:
int32 sf
, the sign flag - offsets 0x34..0x37:
int32 zf
, the zero flag - offsets 0x38..0x3b:
int32 memsize
, the size of allocated virtual memory (500 000 bytes)
There are 16 kinds of instruction, of different sizes. The first byte tells the operation code of the instruction (4 low bits) and whether its execution depends on the SF flag to be set (bit 5, 0x10) or on the ZF flag (bit 6, 0x20).
- If the opcode is between 0 and 9, the instruction is an arithmetic instruction between two operands and is encoded on 10 bytes.
- If the opcode is between 10 and 12, the instruction only has one operand and is encoded on 6 bytes.
- Otherwise, the opcode is between 12 and 15, has no operand and is encoded on one single byte.
When an instruction has an operand, its second byte defines the kind of operand: 1 for an immediate 32-bit value, 2 for a register value and 4 for the value at the address of the given register.
The instructions are (with x
being the first operand and y
the second one):
- opcode 0:
x |= y
(OR) - opcode 1:
x ^= y
(XOR) - opcode 2:
x &= y
(AND) - opcode 3:
x += y
(ADD) - opcode 4:
x -= y
(SUB) - opcode 5:
x *= y
(MUL) - opcode 6:
x /= y
(DIV) - opcode 7:
x %= y
(MOD) - opcode 8:
x <<= y
(SHL) - opcode 9:
x >>= y
(SHR) - opcode A:
PUSH x
- opcode B:
POP x
- opcode C:
CALL x
- opcode D:
RET
- opcode E:
READ(fd=r0, buf=r1, size=r2)
and replace\n
with0
on the first byte of the buffer - opcode F:
WRITE(fd=r0, buf=r1, size=r2)
The instructions are read from .rodata:402280
and the memory of the interpreter is initialized with the content of .rodata:41A920
.
The interpreted program decrypt the data using the following algorithm (written in Python 3):
with open('chall.bin', 'rb') as f:
filedata = f.read()
memdata = filedata[0x1A920:0x1A920 + 43850]
cleardata = bytearray(len(memdata))
for i, x in enumerate(memdata):
cleardata[i] = x ^ (i % 100)
The decrypted data is interpreted as Brainfuck language (https://en.wikipedia.org/wiki/Brainfuck) with the following character conversion:
- 0, 1:
+
(increment the byte at the data pointer, which isr1
) - 2, 3:
-
(decrement the byte at the data pointer) - 4, 5:
<
(decrement the data pointer by one cell, which measures 4 bytes) - 6, 7:
>
(increment the data pointer by one cell) - 8, 9:
[
(conditional jump forwards to the matching]
if the byte at the data pointer is zero) - a, b:
]
(conditional jump backwards to the matching[
if the byte at the data pointer is not zero) - c, d:
.
(write the byte at the data pointer to the standard output) - e, f:
,
(read one byte from the standard input into the byte at the data pointer) - space or
\n
: exit the program
The Brainfuck program is quite simple:
- It begins by writing “What is the magic word ?”
- It then reads the standard input and compare with some values. If the input does not match, it outputs “Ah ah ah! You didn’t say the magic word!” and quits.
- If the input is correct, it outputs “Well done!”
The input which is correct is the key, HIP{f3a306095ecc4dad3d0056ad7b0c135afd89e3127e279e4f906711bf6357f03c}
