Hack In Paris Challenge 5

The challenge began on Friday May, 20th, with a tweet:

#HIPChall n°5 is on!
#BeagleBoneBlack & 2 #goldenticket for #HIP16
Hack, Love, Share, & enjoy!
https://hackinparis.com/challenge-5.html …

The web page contains this message:

Hi!

I was following a white rabbit but I've lost it.
Can you find it for me?

Alice

https://hackinparis.com/data/chall2016/step-5/chall.img

md5:    351804dc726752fda5db3fe69f6c5c34
sha256:    078a5cd5a40e320f0811ef99644e19c5825d81818aa517c6d771860124de3577

Please send your conclusions (and the validation flag) to merenwen@hackinparis.com

chall.img is a FAT32 filesystem labeled challHIP which contains many useless files and a GIF image:

_images/Nothing_to_find_here.gif

Binwalk spots a ZIP archive in this mess:

$ binwalk chall.img

DECIMAL       HEXADECIMAL     DESCRIPTION
--------------------------------------------------------------------------------
1320448       0x142600        GIF image data, version "89a", 350 x 260
2720256       0x298200        Zip archive data, at least v2.0 to extract, compressed size: 18046268, uncompressed size: 22653106, name: file1
20766587      0x13CDF7B       Zip archive data, at least v2.0 to extract, compressed size: 247210, uncompressed size: 281973, name: file2
21013860      0x140A564       Zip archive data, at least v2.0 to extract, compressed size: 4067, uncompressed size: 13383, name: step1.bin
21018223      0x140B66F       End of Zip archive
49586962      0x2F4A312       MySQL MISAM compressed data file Version 7
50839721      0x307C0A9       Certificate in DER format (x509 v3), header length: 4, sequence length: 9733

Let’s extract this 18 MB archive!

$ dd if=chall.img of=chall.zip bs=1 skip=$((0x298200)) count=$((0x0140b684-0x298200+16))
$ unzip chall.zip
Archive:  chall.zip
  inflating: file1
  inflating: file2
  inflating: step1.bin

step1.bin

step1.bin is a Linux program which is very simple to reverse-engineer as it contains all its symbol. The analysis of main() (at .text:4010F3) reveals that this programs can decrypt files which either begin with “Keep me please” or “Keep me too”. As life is well done, the two other files which are part of the initial ZIP archive match these patterns:

$ xxd file1 |head -n1
00000000: 4b65 6570 206d 6520 706c 6561 7365 135b  Keep me please.[

$ xxd file2 |head -n1
00000000: 4b65 6570 206d 6520 746f 6f50 2f4b 2a77  Keep me tooP/K*w

The first file is decrypted with function decryptSimple() at .text:40095D. This function verifies that the key given to the program satisfies a set of basic equations and then decrypt the data. It is possible to solve the equations by hand. It is also possible to use z3 to kindly ask the computer to find the key:

#!/usr/bin/env python2
import z3

# Initialize unknown key
key = z3.BitVec('K', 0x18 * 8)
BYTE_key = [z3.Extract(i + 7, i, key) for i in range(0, key.size(), 8)]

# Translate decryptSimple() instruction to z3 equations
s = z3.Solver()
s.add(BYTE_key[0x15] ^ BYTE_key[0x16] == BYTE_key[0x17] + 0x1D)
s.add(BYTE_key[0x14] ^ BYTE_key[0x15] == BYTE_key[0x16] - 0x69)
s.add(BYTE_key[0x13] ^ BYTE_key[0x14] == BYTE_key[0x15] - 0x69)
s.add(BYTE_key[0x12] ^ BYTE_key[0x13] == BYTE_key[0x14] - 0x0C)
s.add(BYTE_key[0x11] ^ BYTE_key[0x12] == BYTE_key[0x13] + 4)
s.add(BYTE_key[0x10] ^ BYTE_key[0x11] == BYTE_key[0x12] - 0x27)
s.add(BYTE_key[0x0F] ^ BYTE_key[0x10] == BYTE_key[0x11] - 0x18)
s.add(BYTE_key[0x0E] ^ BYTE_key[0x0F] == BYTE_key[0x10] - 0x4E)
s.add(BYTE_key[0x0D] ^ BYTE_key[0x0E] == BYTE_key[0x0F] - 0x48)
s.add(BYTE_key[0x0C] ^ BYTE_key[0x0D] == BYTE_key[0x0E] - 0x73)
s.add(BYTE_key[0x0B] ^ BYTE_key[0x0C] == BYTE_key[0x0D] - 0x2A)
s.add(BYTE_key[0x0A] ^ BYTE_key[0x0B] == BYTE_key[0x0C] - 0x60)
s.add(BYTE_key[0x09] ^ BYTE_key[0x0A] == BYTE_key[0x0B] - 0x1D)
s.add(BYTE_key[0x08] ^ BYTE_key[0x09] == BYTE_key[0x0A] - 0x52)
s.add(BYTE_key[0x07] ^ BYTE_key[0x08] == BYTE_key[0x09] - 6)
s.add(BYTE_key[0x06] ^ BYTE_key[0x07] == BYTE_key[0x08])
s.add(BYTE_key[0x05] ^ BYTE_key[0x06] == BYTE_key[0x07] - 0x0F)
s.add(BYTE_key[0x04] ^ BYTE_key[0x05] == BYTE_key[0x06] - 0x47)
s.add(BYTE_key[0x03] ^ BYTE_key[0x04] == BYTE_key[0x05] - 0x74)
s.add(BYTE_key[0x02] ^ BYTE_key[0x03] == BYTE_key[0x04] - 0x6F)
s.add(BYTE_key[0x01] ^ BYTE_key[0x02] == BYTE_key[0x03] - 0x10)
s.add(BYTE_key[0x00] ^ BYTE_key[0x01] == BYTE_key[0x02] + 0x0A)
s.add(BYTE_key[0x01] + BYTE_key[0x00] == 0x76)
s.add(BYTE_key[0x00] == 0x46)

# Find all solutions
while s.check() == z3.sat:
    m = s.model()
    keyval = m[key].as_long()
    s.add(key != keyval)
    keybytes = b''.join([chr((keyval >> i) & 0xff) for i in range(0, key.size(), 8)])
    print(repr(keybytes))

The output of this Python program is:

'F0llow_7he_White_R4bbit\x00'

To decrypt file1 all what is needed is to run step1.bin:

$ ./step1.bin file1 F0llow_7he_White_R4bbit 2> file1_decrypted.out.b64
Would you like some wine?

$ base64 -d file1_decrypted.out.b64 > file1_decrypted.out
$ file file1_decrypted.out
file1_decrypted.out: RIFF (little-endian) data, AVI, 1280 x 820, ~24 fps,
video: FFMpeg MPEG-4, audio: MPEG-1 Layer 3 (stereo, 44100 Hz)

The function decryptMoreComplex() at .text:400F49 is a more complex: it computes the crypt() hash of the encryption key with two algorithms and salts ($6$4Fz7Ehwg$ and $1$4Fz7Ehwg$) and uses the results to xor the file. Nevertheless if the decrypted file is a base64-encode file like file1, it is possible to crack this algorithm using z3:

#!/usr/bin/env python2
import z3

# Read file2's encrypted data
with open('file2', 'rb') as f:
    data = f.read()
assert data[:0xb] == b'Keep me too'
data = data[0xb:]

# Define the set of valid bytes in the base64 cleartext file
VALID_BYTES = frozenset(
    [ord(x) for x in '\r\n/+='] +
    list(range(ord('0'), ord('9') + 1)) +
    list(range(ord('A'), ord('Z') + 1)) +
    list(range(ord('a'), ord('z') + 1)))


# Define the two crypt() results as unknown variables with conditions
def z3_crypt_b64(val):
    """Return a z3 expression of val being a base64 character from crypt()"""
    return z3.Or(
        z3.And(ord('0') <= val, val <= ord('9')),
        z3.And(ord('A') <= val, val <= ord('Z')),
        z3.And(ord('a') <= val, val <= ord('z')),
        val == ord('.'),
        val == ord('/'))


s = z3.Solver()
hash_alg1 = z3.BitVec('hash1', 8 * 22)
for i in range(0, hash_alg1.size(), 8):
    s.add(z3_crypt_b64(z3.Extract(i + 7, i, hash_alg1)))
hash_alg6 = z3.BitVec('alg6', 8 * 86)
for i in range(0, hash_alg6.size(), 8):
    s.add(z3_crypt_b64(z3.Extract(i + 7, i, hash_alg6)))

# key = hash_alg1 ^ hash_alg6, with cycles (946 is the least common multiple of 22 and 86)
key = z3.BitVec('key', 8 * 946)
for i in range(key.size() // 8):
    i_alg1 = i % 22
    alg1_char = z3.Extract(8 * i_alg1 + 7, 8 * i_alg1, hash_alg1)
    i_alg6 = i % 86
    alg6_char = z3.Extract(8 * i_alg6 + 7, 8 * i_alg6, hash_alg6)
    s.add(z3.Extract(8 * i + 7, 8 * i, key) == alg1_char ^ alg6_char)

# Find available bytes for each byte of the key
for bytepos in range(key.size() // 8):
    selectedbytes = frozenset([ord(data[off]) for off in range(bytepos, len(data), 946)])
    avail_keys = set()
    for k in range(256):
        if all(sb ^ k in VALID_BYTES for sb in selectedbytes):
            avail_keys.add(k)
    assert len(avail_keys) > 0
    keybyte = z3.Extract(8 * bytepos + 7, 8 * bytepos, key)
    s.add(z3.Or([keybyte == x for x in avail_keys]))

# Crack the key
while s.check() == z3.sat:
    m = s.model()
    hash1 = m[hash_alg1].as_long()
    hash6 = m[hash_alg6].as_long()
    s.add(hash_alg1 != hash1)
    hash1bytes = b''.join([chr((hash1 >> i) & 0xff) for i in range(0, hash_alg1.size(), 8)])
    hash6bytes = b''.join([chr((hash6 >> i) & 0xff) for i in range(0, hash_alg6.size(), 8)])
    print("Hash $1$: {}".format(hash1bytes.decode('ascii')))
    print("Hash $6$: {}".format(hash6bytes.decode('ascii')))

    # Decrypt the file
    keyval = m[key].as_long()
    s.add(key != keyval)
    keybytes = [(keyval >> i) & 0xff for i in range(0, key.size(), 8)]
    clearbytes = bytearray(len(data))
    for i in range(len(data)):
        clearbytes[i] = ord(data[i]) ^ keybytes[i % 946]
    with open('file2_decrypted.out.b64', 'wb') as f:
        f.write(clearbytes)

This script finds the two hashes and successfully decrypts file2. However this does not seem to be the intended way of solving this challenge, as the key to decrypt file2 is also buried deep into file1. Let’s describe the standard solving path instead of taking this amazing shortcut!

file1

The decrypted file1 is an MPEG video which contains an hexadecimal line at the bottom, which seems to dump a file. Using ffmpeg to extract the video frames and after doing some custom OCR, the file is extracted:

$ mkdir file1-frames/
$ ffmpeg -i file1_decrypted.out file1-frames/frame%05d.png
$ ./file1_extract_framehex.py
$ file file1_framehex.out
file1_framehex.out.bin: ELF 64-bit LSB executable, x86-64, version 1 (SYSV),
dynamically linked, interpreter /lib64/ld-linux-x86-64.so.2, for GNU/Linux
2.6.24, BuildID[sha1]=796e8cb3fec1f948780986af22fbd1348c3db003, stripped

This function decrypts a payload which is present after the video data with a key which is tested by a function at .text:40084D. A little bit of z3 solving allows to retrieve the encryption key, Have_you_guessed_the_riddle_yet:

$ ./file1_framehex.out file1_decrypted.out Have_you_guessed_the_riddle_yet 2> file1_video_payload.out
Curiouser and curiouser!
$ file file1_video_payload.out
file1_video_payload.out: RIFF (little-endian) data, WAVE audio, Microsoft PCM, 16 bit, stereo 44100 Hz

Running strings on this new file reveals this message:

The first part of the password is "Use_me_to_d3crypt_". It can be used to
decrypt the next step. But, before using it, have you find the second part?

Audacity shows weird peaks in the wave signal of this audio file. This is due to some bytes which have been hidden into the data with a given period. Some experiments lead to extracting one byte every 46907 bytes starting from offset 576:

#!/usr/bin/env python3
import struct

with open('file1_video_payload.out', 'rb') as f:
    # skip header and footer
    WAVDATA = f.read()[44:0x69ed48]

# Extract message
for i in range(576, len(WAVDATA), 46907):
    sample = struct.unpack('b', WAVDATA[i:i+1])[0]
    if sample < 0:
        break
    print(chr(sample), end='')
print('')

The message is:

Congratulation for finding me !

The second part of the password is "the_last_3ncrypted_file"
It can be used to decrypt the next step.
@<;;

The password Use_me_to_d3crypt_the_last_3ncrypted_file can be used to decrypt file2:

$ ./step1.bin file2 Use_me_to_d3crypt_the_last_3ncrypted_file 2> file2_decrypted.out.b64
Begin at the beginning, and go on till you come to the end: then stop.

$ base64 -d < file2_decrypted.out.b64 > file2_decrypted.out
$ file file2_decrypted.out
file2_decrypted.out: ELF 32-bit LSB executable, Intel 80386, version 1 (SYSV),
statically linked, BuildID[sha1]=8c36a356734d8731a544c3d66f2eafc2d25475de, stripped

file2

file2 is a x86-32 bit Linux program which is verifying a password given as a parameter:

$ ./file2_decrypted.out
Usage: ./chall.bin <pass>
$ ./file2_decrypted.out '<pass>'
Wait please...
Oh my ears and whiskers. You are completely wrong :(

This program decrypts itself using XOR encryption with many level of decryption. Too many for attempting to decrypt it by hand, and as the program re-encrypts itself before exiting, it is not possible to catch the exit system call to dump the decrypted program. Moreover strace shows that this program calls signal(SIGTRAP...) many times, with increasing addresses.

gdb can detects that the program reached some deeply-buried addresses using these instructions:

watch *0x080754FD if $pc >= 0x80753F9
commands
break *0x080754FD
continue
end
r pass

gdb would display something similar to:

Starting program: /tmp/chall5/file2_decrypted.out pass
Wait please...

Hardware watchpoint 1: *0x080754FD

Old value = -419722244
New value = -419722923
0x080753fb in ?? ()
=> 0x080753fb:    83 c2 04    add    $0x4,%edx
Breakpoint 2 at 0x80754fd

Hardware watchpoint 1: *0x080754FD

Old value = -419722923
New value = -2082109099
0x080753fb in ?? ()
=> 0x080753fb:    83 c2 04    add    $0x4,%edx
Breakpoint 3 at 0x80754fd

Breakpoint 2, 0x080754fd in ?? ()
=> 0x080754fd:    55    push   %ebp

The backtrace command shows that the program is now under 500 levels of decryption/calls. To extract it:

dump memory file2_clear.out 0x8048000 0x807b000

Some reverse-engineering work leads to understanding that the function at .text:080754FD is testing the password, which is read through a pointer is esi register, by hashing it with an algorithm similar to MD5 but with different constants. Here is the algorithm with the differences with the one from Wikipedia (https://en.wikipedia.org/wiki/MD5):

//Note: All variables are unsigned 32 bit and wrap modulo 2^32 when calculating
var int[64] s, K

//s specifies the per-round shift amounts
s[ 0..15] := { 7, 12, 17, 22,  7, 12, 17, 22,  7, 12, 17, 22,  7, 12, 17, 22 }
s[16..31] := { 5,  9, 14, 20,  5,  9, 14, 20,  5,  9, 14, 20,  5,  9, 14, 20 }
s[32..47] := { 4, 11, 16, 23,  4, 11, 16, 23,  4, 11, 16, 23,  4, 11, 16, 23 }
s[48..63] := { 6, 10, 15, 21,  6, 10, 15, 21,  6, 10, 15, 21,  6, 10, 15, 21 }

// K[0..27] differs with MD5. It is at .text:08075A5B
K[0..63] := {
    0x14F02B43, 0x89C0E4CA, 0x2EE6E47B, 0x177ECEBF,
    0xA20C3D34, 0x5124C3C0, 0x1AEEF40C, 0x31675B41,
    0xCDB50C26, 0xF0789AA0, 0xFB54C0D4, 0xD58AD882,
    0x393E1CD7, 0x04BD0A4B, 0x28C0426E, 0xCA5F186C,
    0xC662BCD1, 0x0F06B131, 0x5A70DAF6, 0x7A7FF510,
    0x7829CDD8, 0xA1EB40D7, 0xDB2A8729, 0xB51A8A3D,
    0xD84E797A, 0xCC1F406D, 0xE182486D, 0x26E4F7DD,
// from K[28..31], the arrays are the same:
    0xA9E3E905, 0xFCEFA3F8, 0x676F02D9, 0x8D2A4C8A,
    0xFFFA3942, 0x8771F681, 0x6D9D6122, 0xFDE5380C,
    0xA4BEEA44, 0x4BDECFA9, 0xF6BB4B60, 0xBEBFBC70,
    0x289B7EC6, 0xEAA127FA, 0xD4EF3085, 0x04881D05,
    0xD9D4D039, 0xE6DB99E5, 0x1FA27CF8, 0xC4AC5665,
    0xF4292244, 0x432AFF97, 0xAB9423A7, 0xFC93A039,
    0x655B59C3, 0x8F0CCC92, 0xFFEFF47D, 0x85845DD1,
    0x6FA87E4F, 0xFE2CE6E0, 0xA3014314, 0x4E0811A1,
    0xF7537E82, 0xBD3AF235, 0x2AD7D2BB, 0xEB86D391,
}

//Initialize variables with custom constants
var int a0 := 0xFD45F22F   //A
var int b0 := 0x1431EE0C   //B
var int c0 := 0x1458EF65   //C
var int d0 := 0x455684AA   //D

//Pre-processing: adding a single 1 bit
append "1" bit to message
//Pre-processing: padding with zeros
append "0" bit until message length in bits ≡ 448 (mod 512)
append original length in bits mod (2 pow 64) to message

//Process the message in successive 512-bit chunks:
for each 512-bit chunk of message
    break chunk into sixteen 32-bit words M[j], 0 ≤ j ≤ 15
//Initialize hash value for this chunk:
    var int A := a0
    var int B := b0
    var int C := c0
    var int D := d0
//Main loop:
    for i from 0 to 63
        if 0 ≤ i ≤ 15 then
            F := (B and C) or ((not B) and D)
            g := i
        else if 16 ≤ i ≤ 31
            F := (D and B) or ((not D) and C)
            g := (5×i + 1) mod 16
        else if 32 ≤ i ≤ 47
            F := B xor C xor D
            g := (3×i + 5) mod 16
        else if 48 ≤ i ≤ 63
            F := C xor (B or (not D))
            g := (7×i) mod 16
        dTemp := D
        D := C
        C := B
        B := B + leftrotate((A + F + K[i] + M[g]), s[i])
        A := dTemp
    end for
//Add this chunk's hash to result so far:
    a0 := a0 + A
    b0 := b0 + B
    c0 := c0 + C
    d0 := d0 + D
end for

var char digest[16] := a0 append b0 append c0 append d0 //(Output is in little-endian)

//leftrotate function definition
leftrotate (x, c)
    return (x << c) binary or (x >> (32-c));

To crack this password, the most straightforward way seems to be to bruteforce it using https://crackstation.net/ wordlist and a C program which rips the function.

/**
 * Test every password from a file with file2's custom MD5-like hash function
 *
 * Usage:
 *     clang -O2 -Wall -m32 runhashes.c -o runhashes.bin
 *     ./runhashes.bin < password_list
 *
 * With JTR:
 *     john --wordlist=john.txt --rules --stdout | ./runhashes.bin
 */
#include <assert.h>
#include <fcntl.h>
#include <stdio.h>
#include <stdint.h>
#include <string.h>
#include <sys/mman.h>

int main(void)
{
    int fd = open("file2_clear.out", O_RDONLY);
    assert(fd >= 0);

    uint8_t *mem = mmap(NULL, 208896, PROT_READ|PROT_EXEC, MAP_PRIVATE, fd, 0);
    assert(mem != MAP_FAILED);

    /* call .text:080754FD function (performs hash and compare)
     * ELF program header:
     *     LOAD off    0x00000074 vaddr 0x08048074 paddr 0x08048074 align 2**4
     *          filesz 0x00032e1c memsz 0x00032e1c flags rw
     * => offset 0x080754FD-0x08048000 = 0x2d4fd
     */
    void *fct_hash_and_test = mem + 0x2d4fd;
    char password[4096];
    int cnt = 0;
    while (fgets(password, sizeof(password), stdin)) {
        size_t len = strlen(password);
        if (len > 0 && password[len - 1] == '\n')
            password[len - 1] = 0;

        uint32_t result;
        __asm__ volatile(
            "call *%[fct]"
            : [res] "=D" (result) /* result is in edi */
            : [fct] "r" (fct_hash_and_test), [pass] "S" (password)
            : "memory", "cc", "%eax", "%ebx", "%edx"
        );
        if (result) {
            printf("success! %s\n", password);
            return 0;
        }
        cnt ++;
        if (cnt % 100000 == 0) {
            printf("(%d) failed %s\n", cnt, password);
        }
    }
    return 1;
}

After less than 30 seconds, this program tested more than 13 million passwords and found bunnyrabbit. Let’s try this with the real program:

$ ./file2_decrypted.out bunnyrabbit
Wait please...
Congratulation! You found the White Rabbit!

      ***
     ** **
    **   **
    **   **         ****
    **   **       **   ****
    **  **       *   **   **
     **  *      *  **  ***  **
      **  *    *  **     **  *
       ** **  **  **       **
       **   **  **
      *           *
     *             *
    *    0     0    *
    *   /   @   \   *
    *   \__/ \__/   *
      *     W     *
        **     **
          *****

The flag is the sha256sum of the password.
Send it (and your write-up if you have one) to merenwen@hackinparis.com

The flag is the SHA256 hash of “bunnyrabbit”, which is 7794db9a8656587526b3764d8f1354614ea13c035fe03fda47dd41bd1e5762a7.
